Apache Kylin Segment Merge Practice: Manual/Auto Merge, Retention Threshold

TL;DR

• Scenario: Incremental build produces multiple small Segments, need to merge to optimize query performance and clean up expired data
• Conclusion: Auto merge + retention policy simplifies operations, JDBC facilitates BI tool integration
• Output: Manual/auto merge operations, retention policy config, JDBC query examples

---

Manual Merge (Merge Segment)

Operation Steps

1. Login to Kylin Web UI
2. Select target Cube
3. Click Action → Merge
4. Select continuous Segments to merge
5. Submit Merge Job

Merge Conditions

• Can only merge continuous Segments
• All Segments participating in merge must be in READY status
• No other build tasks allowed during merge

Merge Job Flow

1. Extract Fact Table - Read each Segment data
2. Merge Cuboid - Merge Cuboid data
3. Convert to HBase - Generate new HBase table
4. Cleanup - Clean temporary files

---

Auto Merge

Config Location

Configure in Cube Designer Refresh Settings:

Multi-level Threshold Strategy

Auto Merge Thresholds:
- 7 days: small Segments per day automatically merged into 7 days
- 28 days: Segments per 7 days automatically merged into 28 days

Trigger Mechanism

1. Triggers when new Segment becomes READY status
2. Attempts merge from largest threshold downward
3. Example: Already have 30 days of data, new Segment triggers attempt to merge into 28 days

Config Example

{
  "auto_merge_time_ranges": "7,28",
  "retention_threshold": 90
}

---

Retention Threshold

Purpose

Automatically clean up expired Segments no longer in use, reduce storage costs.

Calculation Logic

Difference = Latest Segment end time - Current Segment end time
Difference >= threshold → auto delete

Config Example

{
  "retention_threshold": 90  // Retain latest 90 days data
}

---

Delete Segment Flow

Steps

1. Disable Segment - Disable Segment
2. Delete Segment - Delete Segment

Notes

• Must Disable before Delete
• After disabling, Segment doesn’t participate in queries
• After deletion, data cannot be recovered

---

JDBC Connection Query

Maven Dependency

<dependency>
    <groupId>org.apache.kylin</groupId>
    <artifactId>kylin-jdbc</artifactId>
    <version>3.1.1</version>
</dependency>

JDBC Connection Example

import java.sql.*;

public class KylinJDBCDemo {
    public static void main(String[] args) throws SQLException {
        // Connection URL format: jdbc:kylin://host:port/project
        String url = "jdbc:kylin://node2.example.internal:7070/wzk_project";
        String user = "ADMIN";
        String password = "KYLIN";

        try (Connection conn = DriverManager.getConnection(url, user, password)) {
            String sql = "SELECT dt, region, SUM(amount) AS total_amount " +
                        "FROM fact_sales " +
                        "WHERE dt >= '2024-01-01' AND dt <= '2024-01-31' " +
                        "GROUP BY dt, region " +
                        "ORDER BY total_amount DESC";

            try (Statement stmt = conn.createStatement();
                 ResultSet rs = stmt.executeQuery(sql)) {

                while (rs.next()) {
                    System.out.printf("%s | %s | %.2f%n",
                        rs.getString("dt"),
                        rs.getString("region"),
                        rs.getDouble("total_amount"));
                }
            }
        }
    }
}

Query Examples

-- Aggregation query
SELECT dt, category, SUM(amount) AS revenue, COUNT(*) AS orders
FROM fact_sales
JOIN dim_product ON fact_sales.product_id = dim_product.product_id
WHERE dt >= '2024-01-01'
GROUP BY dt, category
ORDER BY revenue DESC
LIMIT 10;

-- Subquery
SELECT region, AVG(avg_amount) AS avg_order_value
FROM (
    SELECT region, dt, SUM(amount) AS avg_amount
    FROM fact_sales
    WHERE dt >= '2024-01-01'
    GROUP BY region, dt
) t
GROUP BY region;

---
